2100 Class - Diesel Electric
<-BACK
The 2100 class was the mainstay of QR's coal haulage from the opening of the Bowen Basin lines through to electrification. After the electrification, they went on to more general freight traffic as well as the non-electrified coal lines, and now most are based in the Brisbane area or central Queensland. Initially, as each new coal mine was planned, a new batch of locos was ordered. The 2100, 2130, 2150, and 2170 classes were ordered for the Goonyella / Peak Downs, Saraji, Norwich Park, German Creek / Oaky Creek / Riverside / Blair Athol mines respectively. The 2141 class (initially the 2200 class) was used for the Greenvale nickel mine.
2100 Class Picture Navigator 2122 of the 2100 class, on a Suburban service to Pinkenba (Photo: )
TECHNICAL DATA
Locomotive Numbers 2100 - 2123 2130 - 2140 2141 - 2148 2150 - 2163 2170 - 2214 Type Diesel-Electric Introduced 1970 Number in class 102; 100 in service Manufacturer Clyde Engineering / Comeng, Rocklea Gauge Narrow Gauge (1,067mm or 3' 6") Axles O°-O°-O°   O°-O°-O° Co-Co Length 18.04m Mass 98t Engine EMD 16-645E Generator EMD D32B (2100 class) EMD AR10 (2130, 2141 Class) AMD AR10-D14 (2150, 2170 Class) Traction Motors EMD D29 Power 1491 kW / 2000 HP Tractive Effort 286 / 226 kN Speed 80km/h (50mph)
CLASS INFORMATION
Locomotive Serial No. In Service Withdrawn Scrapped Comments 2100 70-711 12/1970       2101 70-712 12/1970       2102 70-713 1/1971       2103 70-714 2/1971       2104 70-715 3/1971       2105 70-716 4/1971       2106 71-717 4/1971       2107 71-718 5/1971       2108 71-719 6/1971       2109 71-720 6/1971       2110 71-721 8/1971       2111 71-722 9/1971       2112 72-740 4/1972       2113 72-741 5/1972       2114 72-742 6/1972       2115 72-743 6/1972       2116 72-744 7/1972       2117 72-745 8/1972       2118 72-746 8/1972       2119 72-747 10/1972       2120 72-748 11/1972       2121 72-749 12/1972       2122 72-750 1/1973       2123 72-751 2/1973       2130 74-781 7/1974       2131 74-782 8/1974       2132 74-783 8/1974       2133 74-784 9/1974       2134 74-785 10/1974       2135 74-786 11/1974       2136 74-787 11/1974       2137 74-788 12/1974       2138 74-789 1/1975       2139 74-790 2/1975       2140 74-791 3/1975       2141 73-771 5/1973       2142 73-772 7/1973       2143 73-773 6/1973       2144 73-774 8/1973       2145 73-775 10/1973       2146 73-776 10/1973       2147 73-777 11/1973       2148 73-778 12/1973       2150 79-901 12/1978       2151 79-902 1/1979       2152 79-903 2/1979       2153 79-904 2/1979       2154 79-905 2/1979       2155 79-906 3/1979       2156 79-907 3/1979       2157 79-908 4/1979       2158 79-909 4/1979       2159 79-910 5/1979       2160 79-911 5/1979       2161 79-912 7/1979       2162 79-913 7/1979       2163 79-914 8/1979       2170 82-1100 3/1982       2171 82-1101 3/1982       2172 82-1102 3/1982       2173 82-1103 4/1982       2174 82-1104 4/1982       2175 82-1105 4/1982 8/1989 10/1989   2176 82-1106 5/1982       2177 82-1107 6/1982       2178 82-1108 6/1982       2179 82-1109 6/1982       2180 82-1125 6/1982       2181 83-1146 2/1983       2182 83-1147 2/1983       2183 83-1148 3/1983       2184 83-1149 3/1983       2185 83-1150 3/1983       2186 83-1151 3/1983       2187 83-1152 4/1983 12/1994 10/1996   2188 83-1153 4/1983       2189 83-1154 5/1983       2190 83-1155 5/1983       2191 83-1156 5/1983       2192 83-1157 6/1983       2193 83-1158 6/1983       2194 83-1159 6/1983       2195 83-1160 7/1983       2196 83-1161 7/1983       2197 83-1162 8/1983       2198 83-1218 8/1983       2199 83-1163 8/1983       2200 83-1164 9/1983       2201 83-1165 9/1983       2202 83-1166 9/1983       2203 83-1167 9/1983       2204 83-1168 9/1983       2205 83-1169 10/1983       2206 83-1170 10/1983       2207 83-1171 10/1983       2208 83-1172 11/1983       2209 83-1173 11/1983       2210 83-1174 11/1983       2211 83-1175 12/1983       2212 83-1176 1/1984       2213 83-1177 1/1984       2214 83-1178 2/1984
NAMED LOCOMOTIVES
Locomotive Given Name Comment 2181 P J Goldston P J Goldston was a past Commissioner of Railways
