1550/2400 Class - Diesel Electric
<-BACK
The 1550 and 2400 classes now work typically on general freight traffic around Queensland, along with passenger services. Some of these locos were used in the Bowen Basin prior to electrification, with the 2400, 2450, and 2470 classes seeing work at the Blackwater, Gregory, and Curragh mines respectively. Some of the 1550 class were also used for the Phosphate Hill phosphate mine. Most of the class are based in the central or northern regions of the state. Several of the locos have been rebuilt as the 2300 class, and there will be 60 in all rebuilt.
1550/2400 Class Picture Navigator Class Leader of the 1550 class, in the Corporate Livery (Photo: Frank Archer)
TECHNICAL DATA
Locomotive Numbers 1550 - 1576 (1550 Class) 2400 - 2423 (2400 Class) 2450 - 2467 (2450 Class) 2470 - 2507 (2470 Class) Type Diesel-Electric Introduced 1972 (1550 Class) 1978 (2400, 2450, 2470 Classes) Number in class 27; 10 in service (1550 Class) 80; 74 in service (2400, 2450, 2470 classes) Manufacturer Clyde Engineering / Comeng, Rocklea Gauge Narrow Gauge (1,067mm or 3' 6") Axles O°-O°-O°   O°-O°-O° Co-Co Length 18.04m Mass 92t Engine EMD 12-645E Generator EMD AR10 (1550, 2400 classes) EMD AR10-D14 (2450 class) EMD AR6-D14 (2470 class) Traction Motors EMD D29 Power 1119 kW / 1500 HP Tractive Effort 269 / 226 kN Speed 100 km/h (62.5mph)
CLASS INFORMATION
Locomotive Serial No. In Service Withdrawn Scrapped Comments 1550 72-765 9/1972     To be rebuilt as 2310 1551 72-766 10/1972 3/1999   Rebuilt as 2311 1552 72-767 12/1972 3/1999   Rebuilt as 2312 1553 72-768 1/1973     To be rebuilt as 2313 1554 72-769 2/1973 ?   Rebuilt as 2314 1555 72-770 3/1973 3/1999   Rebuilt as 2315 1556 75-802 7/1975 ?   Rebuilt as 2302 1557 75-803 7/1975 2/1999   Rebuilt as 2303 1558 75-804 8/1976 ?   Rebuilt as 2304 1559 75-805 10/1975 6/1999   To be rebuilt as 2305 1560 75-806 12/1975     To be rebuilt as 2306 1561 75-807 1/1976 ?   Rebuilt as 2307 1562 75-808 2/1976 12/1995 4/1999   1563 75-809 3/1976 ?   Rebuilt as 2308 1564 75-810 3/1976 ?   Rebuilt as 2301 1565 75-811 4/1976 3/1999   Rebuilt as 2309 1566 76-813 5/1976 5/1999   To be rebuilt as 2321 1567 76-814 6/1976 8/1989 9/1989   1568 76-815 7/1976 ?   Rebuilt as 2323 1569 76-816 7/1976     To be rebuilt as 2323 1570 76-817 8/1976 ?   Rebuilt as 2320 1571 76-818 8/1976       1572 76-819 9/1976       1573 76-820 9/1976       1574 76-821 10/1976       1575 76-822 10/1976       1576 76-823 11/1976       2400 76-823 11/1976 3/1999   To be rebuilt as 2330 2401 77-843 5/1977 ?   To be rebuilt as 2331 2402 77-844 6/1977     To be rebuilt as 2332 2403 77-845 6/1977     To be rebuilt as 2333 2404 77-846 7/1977     To be rebuilt as 2334 2405 77-847 7/1977     To be rebuilt as 2335 2406 77-848 8/1977     To be rebuilt as 2336 2407 77-849 8/1977     To be rebuilt as 2337 2408 77-850 9/1977     To be rebuilt as 2338 2409 77-851 10/1977     To be rebuilt as 2339 2410 77-852 11/1977       2411 78-853 11/1977       2412 78-854 12/1977       2413 78-855 1/1978       2414 78-856 2/1978       2415 78-857 2/1978       2416 78-858 3/1978     To be rebuilt as 2346 2417 78-859 4/1978     To be rebuilt as 2347 2418 78-860 5/1978     To be rebuilt as 2348 2419 78-861 5/1978     To be rebuilt as 2349 2420 78-862 6/1978     To be rebuilt as 2350 2421 78-863 7/1978     To be rebuilt as 2351 2422 78-864 8/1978     To be rebuilt as 2352 2423 78-865 9/1978 1/1999   Rebuilt as 2353 2450 79-915 5/1979 5/1999   To be rebuilt as 2355 2451 79-916 6/1979     To be rebuilt as 2356 2452 79-917 7/1979 5/1999   To be rebuilt as 2357 2453 79-918 8/1979       2454 79-919 9/1979     To be rebuilt as 2358 2455 79-920 9/1979       2456 79-921 10/1979       2457 79-922 10/1979       2458 79-923 11/1979       2459 79-924 12/1979       2460 79-925 1/1980       2461 79-926 2/1980       2462 80-946 3/1980     To be rebuilt as 2370 2463 80-947 4/1980       2464 80-948 5/1980     To be rebuilt as 2371 2465 80-949 5/1980     To be rebuilt as 2372 2466 80-950 6/1980     To be rebuilt as 2373 2467 80-951 7/1980 ? ?   2470 81-976 12/1980       2471 81-977 12/1980     To be rebuilt as 2375 2472 81-978 1/1981     To be rebuilt as 2376 2473 81-979 1/1981     To be rebuilt as 2377 2474 81-980 2/1981     To be rebuilt as 2378 2475 81-981 3/1981     To be rebuilt as 2379 2476 81-982 3/1981     To be rebuilt as 2380 2477 81-983 4/1981       2478 81-984 5/1981       2479 81-985 6/1981       2480 81-986 6/1981       2481 81-987 7/1981       2482 81-988 8/1981       2483 81-1006 9/1981       2484 81-1007 10/1981       2485 81-1008 11/1981       2486 81-1009 12/1981       2487 82-1126 6/1982       2488 82-1127 6/1982       2489 82-1128 7/1982       2490 82-1129 7/1982       2491 82-1130 8/1982       2492 82-1131 8/1982       2493 82-1131 9/1982       2494 82-1133 9/1982       2495 82-1134 9/1982       2496 82-1135 10/1982       2497 83-1136 10/1982       2498 83-1137 10/1982       2499 83-1138 11/1982     To be rebuilt as 2385 2500 83-1139 11/1982     To be rebuilt as 2386 2501 83-1140 11/1982     To be rebuilt as 2387 2502 83-1141 12/1982     To be rebuilt as 2388 2503 83-1142 12/1982     To be rebuilt as 2389 2504 83-1143 12/1982     To be rebuilt as 2390 2505 83-1144 1/1983     To be rebuilt as 2391 2506 83-1145 1/1983     To be rebuilt as 2392 2507 81-999 10/1988     Ex Townsville Harbour ST5. To be rebuilt as 2393
NAMED LOCOMOTIVES
Locomotive Given Name Comment 1565 Alva Lee Alva Lee was a past Commisioner of Railways
