1502 Class - Diesel Electric

<-BACK
The 1502's work similar trains to the 1460 class, but over a wider area, and as well, hauled non-electrified suburban trains. So far, four of the locos have also been sold to NZ, and then returned as part of ATN's 2000 class. The 1502's are now in the process of being withdrawn from service with only 10 being kept 'mothballed' at the Redbank workshops.

1502 Class Picture Navigator
2122 of the 2100 class, on a Suburban service to Pinkenba (Photo: )

TECHNICAL DATA
Locomotive Numbers 1502 - 1530
Type Diesel-Electric
Introduced 1967
Number in class 29; 18 in service
Gauge Narrow Gauge (1,067mm or 3' 6")
Axles O°-O°-O°   O°-O°-O°
Co-Co
Length 16.26m
Mass 92t
Engine EMD 12-645E
Generator EMD D32
Traction Motors EMD D29
Power 1119 kW / 1500 HP
Tractive effort 267 / 226 kN
Speed 80 km/h (50mph)

CLASS INFORMATION
Locomotive Serial No. In Service Withdrawn Scrapped Comments
1502 67-597 10/1967 ?   To NZ then to ATN as 2004
1503 67-598 10/1967
1504 67-599 11/1967
1505 67-600 12/1967
1506 67-601 12/1967
1507 67-602 12/1967
1508 67-603 12/1967 ?   To NZ then to ATN as 2003
1509 67-604 1/1968 6/1999
1510 68-605 2/1968
1511 68-606 3/1968
1512 68-607 3/1968
1513 68-608 4/1968
1514 68-609 4/1968
1515 68-610 4/1968
1516 68-611 5/1968
1517 68-612 5/1968 3/1999
1518 68-613 5/1968
1519 68-614 6/1968
1520 68-615 6/1968
1521 68-616 7/1968 ?   To NZ then to ATN as 2001
1522 68-646 11/1968 ?   To NZ then to ATN as 2002
1523 68-647 11/1968
1524 68-648 12/1968
1525 69-649 2/1969 3/1999
1526 69-650 2/1969
1527 69-651 5/1969 11/1998
1528 69-652 6/1969 ?
1529 69-653 7/1969 ?
1530 69-654 8/1969 ?
